ISUZU Emergency Rescue Fire Vehicle FVR 5tons Crane Rescue Fire Truck
Rescue Fire Truck ,which is also called water fire engine,water foam fire truck,fire fighting equipment, fire appliance truck, foam fire tanker, water foam pumper, light rescue apparatus, fire fighting vehicle, foam discharging truck, foam tanker fire truck is a special vehicle designed primarily for fire fighting operations and to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximumly.
Rescue Fire Truck can be divided into several types:
1--According to vehicle size, there are mini fire fighting truck,light fire fighting truck,medium fire fighting truck, heavy-duty fire fighting truck.
2--According to chassis drive type, there are 4X2 or 6-wheel fire fighting truck, 6X4 or 10-wheel fire fighting truck, 8X4 12-wheel fire fighting truck and off-road type 4X4, 6X6 fire fighting truck for military use.
3--According to chassis brand, there are ISUZU fire fighting truck, Dongfeng fire fighting truck, Foton fire fighting truck, FAW fight fighting truck, Shacman fire fighting truck, sinotruk fire fighting truck, Mercedes fire fighting truck, MAN fire fighting truck,Scania fire fighting truck and so on.
4-There are also fire rescue truck with special purpose as follows,
--Foam supply fire truck;
--Compressed air supply fire fighting truck;
--Water tower fire truck ;
--Earthquake rescue fire truck;
Features of isuzu 5tons rescue Fire Fighting Trucks:
---- ISUZU chassis, perfect performance.
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure.
---- High quality fire pump.
---- Massive, durable, long service life.
Spec. of ISUZU Emergency Rescue Fire Vehicle FVR 5tons Crane Rescue Fire Truck
| Model | Parameters | others |
| Overall Dimension | 8055×2500×3500 | |
| GVW | 16000kg | |
| Engine Model | 6HK1-TCNG40 | |
| Engine Power | 177kW | |
| Wheelbase | 4500mm | |
| Driving Type | 4×2 | |
| Max.speed | 90km/h | |
| Emission Standard | 7790ml | Euro4 |
| Passengers | 2+4 | |
| Approach angle | ≥26° | |
| Departure angle | ≥12° | |
| Generator | 10KW | SHT11500 |
| Lifting lamp | 4×1000W,Height≥7.5M | YZH4-5.04CA |
| Traction winch | 5443kgf | N12000XF |
| Crane | 5000kg | SQ5ZK2 |
The accessories equipment list
| Item | Item | parameters | unit | quantity |
| 1 | Portable dry powder fire extinguishers | 2kg | piece | 1 |
| 2 | Bucket | piece | 2 | |
| 3 | Triangle Warning board | piece | 2 | |
| 4 | sole timber for crane | piece | 2 | |
| 5 | Spare light tube | piece | 2 | |
| 6 | Original chassis tools and accessories | piece | 1 |
